    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory

    Ask Lasest Price
    Brand Name : Lanjing
    Model Number : LANJING-1
    Certification : ICR Polska/VC/HS221231
    Price : 1000-1500 Square Meters $45-50;1500-2000 Square Meters $42-45;2000-3000 Square Meters $40-42;
    Payment Terms : T/T
    Supply Ability : 30000T/year
    Delivery Time : 36-45 days
    • Product Details
    • Company Profile

    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory


    Product Details


    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory


    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory


    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory


    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory







    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory

    Specification


    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory

    When contrasted with conventional buildings, steel - structured buildings represent a novel form of construction. In these buildings, the entire edifice is fabricated from steel. The structure mainly consists of steel beams, columns, trusses, and other components crafted from section steel and steel plates. Connections between components are achieved through welding, bolts, or rivets. Owing to their lightweight nature and uncomplicated structures, they find extensive applications in large - scale factories, stadiums, super - tall buildings, and other fields. The types of steel - structured buildings include the portal rigid - frame, frame structure, truss structure, and grid structure.
    The portal rigid steel frame has a simple structure and clear force - transmission paths. This makes construction fast and cost - effective. It's widely used in industrial buildings like factories, as well as small - scale commercial structures due to its straightforward assembly and economic advantages.
    Frame structures offer great flexibility. They can create large, open - plan spaces, which is why they are popular in multi - story commercial office buildings, shopping malls, and conference centers. The ability to adapt the interior layout according to different functions is a major plus.
    Truss structures are made by combining small - cross - section components into larger, more robust units. They are ideal for applications that require long - span coverage, such as large - span roofs of stadiums, bridges, and some industrial workshops where a wide, unobstructed space is needed.
    Grid structures, composed of an intricate network of rods, are highly rigid and have excellent seismic resistance. They are often used in large public buildings like gymnasiums, exhibition halls, and airport terminals, where a large, stable space with good aesthetic appeal is required.

    Material Description
    Main Structure

    Including Column & Beam, Made of welded H section Steel, Steel Grade Q355B/Q235B

    Column & Beam Connection: High Strength Bolt

    Column & Foundation Connection: Pre-embedded Anchor Bolt

    Secondary Structure

    Roof Purlin & Wall Purlin: C-shape or Z-shape Steel

    Knee Brace: Angle Steel

    Brace: Steel Rod

    Tie Bar: Steel Pipe

    Types of wall panels and roof panels

    Applicable Regions and Scenarios

    Color Steel Sheet

    Areas without winter, preferred for processing workshops and warehouses

    Color Steel Sheet & Fiberglass Roll Insulation

    Areas with winter but with low requirements of temperature , preferred for warehouses and workshops

    Insulated Sandwich Panel

    Workshops and warehouses with temperature requirements

    PU Insulated Sandwich Panel

    Workshops, warehouses and public facilities with high requirements of temperature for the working environment

    Product packaging


    Metal Structure Factory Steel Buildings , Portal Frame Steel Construction Factory

    FAQ

    1. What kind of customer service do you provide?
    We offer comprehensive customer service, including basic design,supporting facilities procurement, and the option to dispatch installation guidance.

    2. How about the customer reviews of your company?
    We are proud to have received consistently high five-star reviews from our customers, which stand as a testament to our commitment to quality and service.

    3. What is your quality inspection process like?
    Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished goods, each stage is meticulously inspected to guarantee superior quality.

    4. Can you send engineers or a whole team to install my project?
    We will give detailed installation drawings for free. We can send engineers as an installation director or a team upon request.

    5. Do you accept container loading inspection?
    You are welcomed to send an inspector, not only for the container loading, but any time during the production time.

    6. Do you offer designing service for us?
    Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial buildings like office mansions, super markets, auto dealer shops, shipping malls, 5-star hotels.

    7. What is the delivery time?
    Delivery time depends on order quantities. In general, the delivery time to the nearest seaport in China will be 40 days after
    receiving the deposit.

    8. How can I get a quotation for my projects?
    You can contact us by email, phone, Trade manager and so on 24*7 and you will get a reply within 8 hours.

    9. What certifications has your company passed?
    Our company has passed professional certifications such as IOS9000, CE, and SGS, ensuring that our products and services meet international standards.
